Prime 12" R2S Shallow Loaded Enclosure R2S-1X12
Prime 12" R2S Shallow Loaded EnclosureR2S-1X12
The R2S-1X12 is a single 12” shallow enclosure with 250 Watts RMS power handling wired to a 2-Ohm load. The enclosure is constructed with 5/8” MDF, covered in high density carpet, and features quick release compression terminals.
When you have no space for bass, our PRIME R2S 12" shallow loaded enclosure is sure to be a perfect fit for your ride and your budget. These shallow loaded enclosures can fit in tight spaces due to the slim-line depth of 3.25" on the top and 5.25" on the bottom. The wedge design is optimized for single-cab trucks with limited seat travel. Are you ready to rock out? Yeah, we thought so.
General Specifications
Nominal Impedance (ea)
2-Ohm
Internally wired to create a 2-Ohm amplifier load
Power Handling (Watts RMS)
250 Watts RMS
500 Watts Max
Enclosure Type
Shallow
Woofer Quantity
1
Woofer Size
12"
Woofer Series
Prime R2 Shallow (R2SD4-12)
Speaker Connector
Up to 12 AWG Compression Terminals
Dimensions
Box (H x W x D)
Wedge (H x W x D1 x D2)
13.5" x 27.375" x 5.25" (bottom) x 3.25" (top)
34.29cm x 69.53cm x 13.34cm (bottom) x 3.25cm (top)
Enclosure Material
5/8" MDF
CEA-2031 Compliant
Shipping Weight
24.6 Lbs. (11.15 Kg)
